11. THREADING THE MACHINE

• THREADING DIAGRAM

* A color coded threading diagram is located inside

the looper cover for quick reference.

* Thread the machine in the order 0 to @ as

shown.

* UNDERSTANDING THE COLOR CODE

* Left needle thread — Blue ®

* Right needle thread - Green @

* Upper looper thread — Orange 0

* Lower looper thread — Yellow 0

STITCH DIAGRAM

* Right needle thread

* Left needle thread ~ Blue

~ Orange

~ Yellow

— Green

~ Blue

• TO THREAD THE MACHINE

CORRECTLY

(1) Threading the Upper Looper (Orange)

* Thread the upper looper as indicated ® ®

0 @ ® (D

d“

4 THREADS

3 THREADS

LEFT RIGHT

NEEDLE NEEDLE

Topside

Underside
